Product Description:

The Hysteresis dynamometer, specifically the AHD series, is a versatile and optimal tool for conducting low and medium power testing. Traditional dynamometers generate torque through speed, but the Hysteresis brake operates differently, and therefore can be tested from no load to locked rotor.

The AHD series of dynamometers are highly adaptable, and can be used in a variety of settings. They are also incredibly reliable, ensuring consistent and accurate testing results. This makes them a top choice for many industries, including automotive, aerospace, and industrial testing.

The Hysteresis brake technology also offers many advantages over traditional dynamometers. It doesn't rely on heavy cooling systems, and can operate safely at high speeds. Additionally, it provides extremely precise measurements, allowing for more nuanced and detailed analysis during testing.

Features:

The Hysteresis Dynamometer, also known as AHD series, is an ideal testing instrument for low and medium power testing. Unlike other devices, hysteresis brakes generate torque without relying on speed. Hence, it can be tested from no load to locked rotor. Depending on the model, brake cooling is provided by convection cooling (no wind source) or air cooling (compressed air AHD series or blower BHD series).

The Hysteresis Dynamometer offers continuous and short-term intermittent power to radiate more heat range. It has an accuracy of ±0.25% to ±0.5% of full scale, based on the size and system composition of the dynamometer. In addition, it provides special designs for high-speed motor testing.

This instrument finds its application in the performance testing of various AC and DC motors such as torque, speed, power, etc. It is widely used in the detection of automobile motors, household appliance motors, electric tool motors, compressor motors, and aviation motors.

Technical Parameters:

The dynamometer comes with 12 standard specifications, ranging from peak torque of 0.1kg·cm to 50kg·cm. It features a hysteresis brake system that ensures accurate torque load that is independent of speed. The motor is tested both from a no-load state to a blocked state to ensure its effectiveness. An accuracy of ±0.25% to ±0.5% (full scale) is achieved through the use of high-precision load and speed sensors. Furthermore, an airflow detection function is included to prevent overheating and possible operator errors. The base of the dynamometer comes as an optional long plate type or short plate type, making it adaptable to different settings.

For specialized needs, a customized dynamometer is available to cater to special requirements for both torque and speed. The dynamometer can also be easily adjusted with the use of weights. There are several models of the dynamometer available, each with a maximum torque range, five-minute short-term power, long-term operating power, maximum speed, and a cooling type.

Applications:

• Research and development laboratories
• Manufacturing facilities
• Quality control departments
• Engineering firms

With the PWHD Hysteresis Dynamometer, users can easily and accurately measure the magnetic retentivity and torque of a wide range of materials and components. This makes it an ideal tool for testing and evaluating the performance of various products, including:

• Motors and generators
• Gears and gearboxes
• Springs and other mechanical components
• Magnetic materials and components

The PWHD Hysteresis Dynamometer is compatible with both Windows and Mac operating systems, making it easy to use with a wide range of software programs. With its compact dimensions of 200mm X 300mm X 100mm and lightweight design of 2.5 - 30 Kg, it is a portable and convenient tool that can be easily transported and used in different locations.

The operating temperature range of 10-40°C ensures that the PWHD Hysteresis Dynamometer can be used in a variety of environments, and its durable construction ensures that it can withstand the demands of heavy use over time. Additionally, the product comes with a 1-year warranty, providing users with peace of mind and ensuring that their investment is protected.

In conclusion, the Precision Motive PWHD Hysteresis Dynamometer is an essential tool for anyone who needs to measure magnetic retentivity and torque. Whether you are working in a research and development laboratory, a manufacturing facility, a quality control department, or an engineering firm, this product is sure to meet your needs and exceed your expectations.
